The UDM12R is a rugged, IP68-rated integrated UHF RFID reader from Virtualsphere, built around a high-performance Chinese RFID reader module compliant with ISO18000-6C (EPC Gen2). Combining a long-ran…
₹27,000
GST as applicable · per unit, minimum order 5
Low Stock2 units available
The UDM12R is a rugged, IP68-rated integrated UHF RFID reader from Virtualsphere, built around a high-performance Chinese RFID reader module compliant with ISO18000-6C (EPC Gen2). Combining a long-range circular-polarized antenna, adjustable RF output, and flexible Wiegand/RS232/POE/WiFi/RJ45/GPIO connectivity, the UDM12R is designed for access control, vehicle identification, warehousing, and asset-tracking deployments that demand reliable outdoor performance. Model Name UDM12R Comm Interface RS - 232, RJ45, GPIO, Wigand 485, Wifi (Optional), POE (Optional) Color: White Material: Plastic + Aluminium Housing Material: ABS Baud Rate: 115200bps Working Frequency: 862 or 870 MHz band (We can do as per your requirements) Engine: VM-310 based on Impinj E310 chip Protocol: EPC global UHF Class 1 Gen 2 / ISO 18000-6C Input Impedance: 50Ω VSWR ≤1.3 Language: C#, Java, C Language (Easy access/ Integrate Through API )
